Borac

Tags

IMG_1408

IMG_1413

IMG_2767

IMG_2768

Enter Title

General
YARDNUMBER	332914
IMO NUMBER	9438767
OWNER	Brodospas
MANAGER	Brodospas - Split
FLAG	CROATIA
DATE OF DELIVERY	25. March 2008
VESSEL BUILT	Strategic Marine (Singapore) Pte.Ltd
HULL MATERIAL	Aluminium
SUPERSCRUCTURE	Aluminium
BASIC FUNCTIONS	Fast supplier, crew boat
CLASSIFICATION	Bureau Veritas / CRS

Dimensions
LENGHT O.A.	40,37 m
BEAM O.A.	7,50 m
DEPTH AT SIDES	3,23 m
DRAUGHT AFT (APPROX.)	2,30 m
GROSS TONNAGE	220
NET TONNAGE	95

Capacities
FUEL OIL	60.00 m3
CARGO FRESH WATER	25.00 m3
WASTE WATER	0.50 m3
DIRTY OIL	0.2 m3
DECK TANKS	-
PASSENGERS	50 persons
DECK SPACE	110.00 m2
DECK STRENGTH	1.6 t/m2

Performance
SPEED (TRIALS)	27 knots
OPERATIONAL SPEED	24 knots
ECONOMIC SPEED	21 knots

Propulsion system
MAIN ENGINES	2 x Cummins KTA 38 M2 1 x Cummins KTA 50 M2
TOTAL POWER	2 x 1007 kW@1900 ok/min 1 x 1342 kW@1900 ok/min (3356 kW)
GEARBOXES	2 x twin disc MGX 6690 SC 1 x twin disc MGX 6848 SC
PROPELLERS	3 x Fixed pitch propellers

Electrical equipment
GENERATOR SET(S)	2 x 80 Kw; 230V/400V 50 Hz

Deck lay-out
ANCHOR	HHP 202,5 kg
ANCHOR WINCH	Hypac HHAW5-32 el.hydraulic

Life saving equipment
LIFE BUOYS	6
LIFE JACKETS	67
LIFE RAFTS	2 x 50, 2 x 20
FIRE MAN’S OUTFIT	5 x incl. 1 x fire axe
WORK BOAT	RB-400 with outboard motor 25 hp 1 x 6 men semi
INTERNAL FIRE-FIGHTING	Fixed gas flooding system Engine Room CO2 Portable extinguishers according to class Portable extinguishers according to class

Auxiliary systems
SPRAY SHIELD ON DECK	Fitted around the hull at deck level
MECH. VENTILATION	Axial flow fans
BOWTHRUSTERS	1 x 98 kW, Hydraulic

Accommodation
OFFICERS CABIN	2 x 1 persons
CREW CABIN	2 x 2 persons, 1 x 4 persons
SUPERNUMERARIES SEATS	50
AIR-CONDITIONING	Air Conditioning in wheelhouse and accommodation
CREW	6 PERSONS
SUPERNUMERARIES	50 PERSONS

Nautical and Communication equipment
CALL SIGN.	9A4827
SEARCHLIGHT	2 x 500 Watt
RADAR	1 x Foruno 1932 Mark 2 1 x Radar Arpa Kelvin Hughes
MAGNETIC COMPASS	Rittchi power damp
ECHO SOUNDER	JMC-V-60202
GPS NAVIGATOR	Foruno GP-32
VHF	Foruno
HF/MF	Foruno
PA/LOUDHAILlNG SYSYTEM	Uller
SATCOM	Fleet phone unit, terminal beam oceana 800
NAVTEX	SNX-300
AUTOPILOT	Navicontrol AP 3003 GOLD
AIS	JRC JHC - 182
