Reful

« Prev Page(s): 1 2 Next »

General
IMO NUMBER	8877978
FORMER NAME	"STERLJKO", "ARROW"
OWNER	BRODOSPAS - SPLIT
MANAGER	BRODOSPAS - SPLIT
COUNTRY AND PORT OF. REG.	CROATIA, SPLIT
DELIVERED	1979
VESSEL BUILT	SWIFTSHIP INC. MORGAN CITY USA
CLASSIFICATION	CROATIAN REGISTER ★90A1 3 SUPPLY VESSEL SD ★M1

Dimensions
LENGHT O.A.	38,10 m
LENGHT ARTICLE 2 (8)	33,20 m
BREADTH MOULDED	7,09 m
DEPTH MOULDED	-
DRAFT	2,39 m
FREEBOARD	-
TONNAGE - DEAD WEIGHT
GROSS TONNAGE	162
NET TONNAGE	49
DEADWEIGHT	60 tons

Deck
LOADING CAPACITIES
DECK MEASUREMENTS	92 m2
DECK CARGO CAPACITY	60 tons (MAX.)
DECK STRENGHT - AFT PART	0,5 tons / m2
DECK CRANE SHIPS SERVICE	SWL 910kg

Anchor
ANCHOR TYPE	DENFORTH, WEIGHT: 92 kg , CABLE DIA: 13, CABLE LENGHT 100 mtrs
ANCHOR WINDLASS	MAKE: TULSA - 34

Bridge - navigation equipment
MANOEUVRING CONTROL POSITION	TWO
1x RADAR MAKE: FURUNO	TYPE: FR 8100 D
MAGNETIC COMPASS	MAKE: KOMPAS RIJEKA TYPE: 120
ECHO SOUNDER	MAKE: INTERPHASE TYPE: ADVANTAGE
SATELLITE NAVIGATOR	MAKE: INTERPHASE TYPE: CHART MASTER 11 CVS+
SART	Mc Murdo S-4
EPIRB	JOTRON TYPE: 97780
NAVTEX	FURUNO TYPE: NX 500
FLEET 33	T&T

Liquid capacities
POTABLE WATER CAPACITY	59 m3
FUEL OIL CAPACITY - TOTAL	37 m3

Boats
INFLATABLE LIFE RAFTS	No.: SIX TOTAL CAPACITY: 6x20 PERSONS

Engines
MAIN ENGINES
MAKE	MTU TYPE: 12V 331 TC81
BORE	165 mm STROKE: 155 mm
KILO WAT RATING BRAKE	kW: 2x820 TOTAL kW: 1640
AUXILIARIES / ELECTRIC POWER
MAKE	KATO
GENERATORS	2x37,5 kVA
TOTAL GENER/ELEC. POWER	75 kVA
VOLTAGE	220/380 V
FREQUENCY	50Hz
MAIN PROPELLERS	2 PROPELLERS
SPEED/CONSUMPTION
MAX. CRUISING SPEED	19 KNOTS, CONSUMPTION: 9 TONS, RANGE:4 DAYS
ECON. CRUISING SPEED	17 KNOTS, CONSUMPTION: 6,2 TONS, RANGE: 5 DAYS

Radio
CALL SIGN	9A2243
R/T (SSB) MAKE:	SAILOR COMPACT HF SSB RE 2110
VHF MAKE:	SAILOR COMPACT VHF RT 2048 FURUNO - MODEL FM - 8800 S DEBEG - 6310

Accomodation
CREWCABIN No.	4
CREW	6 PERSONS + 44 SUPERNUMERARIES TOTAL: 50
