Altair


General
IMO NUMBER 8030831
OWNER BRODOSPAS - SPLIT
MANAGER BRODOSPAS - SPLIT
COUNTRY AND PORT OF. REG. CROATIA, SPLIT
DELIVERED 1982.
CLASIFICATION CROATIAN REGISTER
VESSEL BUILT BRODOGRADILIŠTE "J.L. MOSOR" TROGIR
Dimensions
LENGHT OVERALL 26,10m
LENGHT ARTICLE 2 (8) 24,14m
BREADTH MOULDED 8,80m
DEPTH, MOULDED, MIDSHIP 4,05m
DRAFT 3,40m
GROSS TONNAGE 230 TONS
NET TONNAGE 69 TONS
Tank Capacities
FUEL OIL TANKS 80 m3
FRESH WATER TANKS 20 m3
FOAM TANKS 10 m3
BILGE COLLECTING TANK 2 m3
SEWAGE COLLECTING TANK 6 m3
BALLAST TANK 30 m3
Speed, bollard pull
TRIAL SPEED AT 3,10 DRAFT, AND 1425kW 13 kN
BOLLARD PULL 29 TONS
CRUISING RANGE 80% MCR 2400 Nm
Towing gear & equipment
TOWING HOOK One 30 kN SWL.
Remote and local quick release.
CAPSTAIN One, electrically driven, 25 kN at 12 m/min
Remote and local quick release.
WINDLASS One, electrically driven windlass with two warping ends.
ANCHORS AND CHAINS Two bower anchors, 480 kg each, chain 248 m dia 18 mm, U2 quality.
Bridge, navigational equipment
BRIDGE, NAVIGATIONAL EQUIPMENT One radar, magnetic compass, VHF radiotel.
Accomodation
ACCOMODATION High standard accomodation for 6 persons, including two single and two double with common toilet space.
Life saving appliances
LIFE SAVING APPLIANCES Two inflatable liferalts, 6 persons each.
Propulsion machinery
MAIN ENGINES Two "MAN-SPLIT" 8L 20/27; 2x720 kW
TRANSMISSION One inclined shaft with two universal joints and elastic coupling for each engine.
MAIN PROPELLERS Two thrusters, made by Liaaen tyoe ten 83/56-210
The thrusters have four bladed C.P. propelier 360' rotateable and fitted with nozzles.
ELECTRIC GENERATOR Two sets, 125 kVA each, 380 V, 50 Hz, AC
Firefighting system
FIREFIGHTING SYSTEM Two pumps of 250 m3/h, 13 bar, driven by main engines.
Radio
CALL SIGN 9A6581
Automation, control & monitoring
AUTOMATION, CONTROL & MONITORING
Control and monitoring of main engines, thruster, towing winches etc.
from wheelhouse.
Engine room console for control and monitoring of machinery and ship systems.
