General
| IMO NUMBER |
8133803 |
| OWNER |
BRODOSPAS d.d. - SPLIT |
| MANAGER |
BRODOSPAS - SPLIT |
| COUNTRY AND PORT OF REGISTRATION |
CROATIA - SPLIT |
| VESSEL BUILT AT |
GOROKHVETZ-1979. UKRAINA |
| CLASSIFICATION |
CROATIAN REGISTER |
Dimensions
| LENGHT OVER ALL |
29,3 m |
| LENGHT ON DESIGN WATERLINE |
28,2 m |
| LENGHT BETWEEN PERPENDICULARS |
27,0 m |
| BREADTH ON UPPER DECK |
8,3 m |
| BREADTH ON DESIGN WATERLINE |
8,2 m |
| DRAUGHT, MEAN, ON DESIGN WATERLINE |
3,2 m |
| DISPLACEMENT OF THE AFORESAID |
319 t |
| BRT/GROSS TONNAGE |
184 |
Speed and pull on hook
Free running speed in deep waters at full displacement, with the state of sea
to 2, is to be not less than 11,0 knots |
Bollard pull - 20 TONS Tank capacities
| DIESEL OIL |
36,0 t |
| LUBRICATING OIL |
2,0 t |
| FEED WATER |
4,1 t |
| DRINKING AND WASHING WATER |
1,8 t |
The said stores of diesel oil and lubricating oil are to provide for the
operation of the main engines at full speed for not less than 150 hours.
Fire-fighting systems
Water fire-fighting system - used as a fire pump-centrifugal vertical
electric pump capacity 25 m3/h; head 65 m w.g. |
Foam fire-fighting / salvage pump / diesel motor-driven fire pump;
capacity 220 m3/h / head 105 m w.g. |
| Tank with foam agent capacity 0,5m3 |
| foam mixer |
Arrangment of machinery installation
| MAIN ENGINE |
LENIGRADSKI ZAVODI, GD 30/50 4E,
2 x 441 kW |
| GENERATOR |
1 SHAFT; 1 DIESEL |
