Borac
General
YARDNUMBER
332914
IMO NUMBER
9438767
OWNER
Brodospas
MANAGER
Brodospas - Split
FLAG
Croatia - Split
DELIVERED
25. March, 2008
VESSEL BUILT
Strategic Marine (Singapore) Pte.Ltd
HULL MATERIAL
Aluminium
SUPERSTRUCTURE
Aluminium
BASIC FUNCTIONS
Fast supplier, crew boat
CLASSIFICATION
Bureau Veritas / Croatian Register
I
HULL
MACH
Dimensions
LENGHT O.A.
40.37 m
BEAM O.A.
7.50 m
DEPTH AT SIDES
3.23 m
DRAUGHT AFT (APPROX.)
2.30 m
GROSS TONNAGE
220 t
NET TONNAGE
95 t
Capacities
FUEL OIL
60.00 m
3
CARGO FRESH WATER
25.00 m
3
WASTE WATER
0.50 m
3
DIRTY OIL
0.2 m
3
DECK TANKS
-
SUPERNUMERARIES
50 persons
DECK SPACE
110.00 m
2
DECK STRENGTH
1.6 t/m
2
Performance
SPEED (TRIALS)
27 kn
OPERATIONAL SPEED
24 kn
ECONOMIC SPEED
21 kn
Propulsion system
MAIN ENGINES
2 x Cummins KTA 38 M2
1 x Cummins KTA 50 M2
TOTAL POWER
2 x 1007 kW@1900 ok/min
1 x 1342 kW@1900 ok/min
(3356 kW)
GEARBOXES
2 x twin disc MGX 6690 SC
1 x twin disc MGX 6848 SC
PROPELLERS
3 x Fixed pitch propellers
Electrical equipment
GENERATOR SETS
2 x 80 kW; 230V/400V 50 Hz
Deck lay-out
ANCHOR
HPP 202.5 kg
ANCHOR WINCH
Hypac HHAW5-32 el.hydraulic
Life saving equipment
LIFE BUOYS
6
LIFE JACKETS
67
LIFE RAFTS
2 x 50, 2 x 20
FIRE MAN’S OUTFIT
5 x incl. 1 x fire axe
WORK BOAT
RB-400 with outboard motor 25 hp
1 x 6 man
FAST RESCUE CRAFT
4.70 m MOB with outboard motor 25 hp
INTERNAL FIRE-FIGHTING
Fixed gas flooding system Engine Room CO2
Portable extinguishers according to class.
Auxiliary systems
SPRAY SHIELD ON DECK
Fitted around the hull at deck level
MECH. VENTILATION
Axial flow fans
BOWTHRUSTERS
1 x 98 kW, Hydraulic
Accommodation
OFFICERS CABIN
2 x 1 persons
CREW CABIN
2 x 2 persons, 1 x 4 persons
SUPERNUMERARIES SEATS
50
AIR-CONDITIONING
Air Conditioning in wheelhouse and accommodation
CREW
10 persons
SUPERNUMERARIES
50 persons
Nautical and Communication equipment
CALL SIGN
9A4827
SEARCHLIGHT
2 x 500 Watt
RADAR
1 x Furuno 1932 Mark 2
1 x Radar Arpa Kelvin Hughes
MAGNETIC COMPASS
Rittchie power damp
ECHO SOUNDER
JMC-V-60202
GPS NAVIGATOR
Furuno GP-32
VHF/DSC
Furuno
HF/MF
Furuno
PA/LOUDHAILlNG SYSYTEM
Uller
SATCOM
Fleet phone unit, terminal beam oceana 800
NAVTEX
SNX-300
AUTOPILOT
Navicontrol AP 3003 GOLD
AIS
JRC JHC - 182
