General
| IMO NUMBER |
8428478 |
| OWNER |
Brodospas |
| MANAGER |
Brodospas - Split |
| FLAG |
Croatia - Split |
| DELIVERED |
1980 |
| VESSEL BUILT |
Gorokhovets shipyard - Gorokhovets, Russia |
| CLASSIFICATION |
Croatian Register |
Dimensions
| LENGHT OVER ALL |
29.3 m |
| LENGHT ON DESIGN WATERLINE |
28.2 m |
| LENGHT BETWEEN PERPENDICULARS |
27.0 m |
| BREADTH ON UPPER DECK |
8.3 m |
| BREADTH ON DESIGN WATERLINE |
8.2 m |
| DRAUGHT, MEAN, ON DESIGN WATERLINE |
3.2 m |
| DISPLACEMENT OF THE AFORESAID |
319 t |
| GROSS TONNAGE |
184 t |
| NET TONNAGE |
59 t |
Speed, bollard pull
| TRIAL SPEED |
Free running speed in deep waters at full displacement, with the state of sea to 2, is about 11.0 kn |
| BOLLARD PULL |
The pull on hook at speed of 3 kn in deep waters is 17.0 t. |
Tank capacities
| DIESEL OIL |
36.0 t |
| LUBRICATING OIL |
2.0 t |
| FEED WATER |
1.8 t |
| DRINKING AND WASHING WATER |
4.1 t |
The said stores of diesel oil and lubricating oil are to provide for the
operation of the main engines at full speed for not less than 150 hours.
Fire-fighting system
| FIRE-FIGHTING EQUIPMENT |
Water fire-fighting system - used as a fire pump-centrifugal vertical
electric pump capacity 25 m3/h; head 65 m w.g. |
| |
Foam fire-fighting / salvage pump / diesel motor-driven fire pump;
capacity 220 m3/h / head 105 m w.g. |
| |
Tank with foam agent capacity 0.5m3 |
| |
foam mixer |
Arrangment of machinery installation
| MAIN ENGINE |
LENIGRADSKI ZAVODI, GD 30/50 4E,
2 x 441 kW |
| GENERATOR |
1 SHAFT; 1 DIESEL |
