Argus


General
IMO NUMBER 8133803
OWNER Brodospas
MANAGER Brodospas - Split
FLAG Croatia - Split
DELIVERED 1978
VESSEL BUILT Gorokhovets shipyard - Gorokhovets, Russia
CLASSIFICATION Croatian Register
Dimensions
LENGHT OVER ALL 29.3 m
LENGHT ON DESIGN WATERLINE 28.2 m
LENGHT BETWEEN PERPENDICULARS 27.0 m
BREADTH ON UPPER DECK 8.3 m
BREADTH ON DESIGN WATERLINE 8.2 m
DRAUGHT, MEAN, ON DESIGN WATERLINE 3.2 m
DISPLACEMENT OF THE AFORESAID 319 t
GROSS TONNAGE 184 t
NET TONNAGE 59 t
Speed, bollard pull
TRIAL SPEED  Free running speed in deep waters at full displacement, with the  state of sea to 2, is about 11.0 kn
BOLLARD PULL  The pull on hook at speed of 3 kn in deep waters is 17.0 t.
Tank capacities
DIESEL OIL 36.0 t
LUBRICATING OIL 2.0 t
FEED WATER 1.8 t
DRINKING AND WASHING WATER 4.1 t
The said stores of diesel oil and lubricating oil are to provide for the
operation of the main engines at full speed for not less than 150 hours.
Fire-fighting system
FIRE-FIGHTING EQUIPMENT Water fire-fighting system - used as a fire pump-centrifugal vertical
electric pump capacity 25 m3/h; head 65 m w.g.
  Foam fire-fighting / salvage pump / diesel motor-driven fire pump;
capacity 220 m3/h / head 105 m w.g.
  Tank with foam agent capacity 0.5m3
  foam mixer
Arrangment of machinery installation
MAIN ENGINE LENIGRADSKI ZAVODI, GD 30/50 4E,
2 x 441 kW
GENERATOR 1 SHAFT; 1 DIESEL
Radio
CALL SIGN 9A2300
